The on-board charger is built in the new energy vehicle, which is used to charge the on-board high-voltage battery from the AC grid when parking. The battery used is usually more than 400V, and is developing towards higher voltage and higher number of battery strings. In order to realize a faster and lighter vehicle charging scheme, the new trend of charging power is upgraded from 6.6kw to 11kw. Generally, the current flows from the grid to the battery in one direction, but there are also two-way flow design schemes. Nano chip micro provides complete solutions for isolation voltage, isolation current detection, isolation drive and isolation communication, helping customers achieve higher power density OBC solutions.
Application document
GB/T7349
IEC62052-11/GB/T 17215.211
GB/T 17215.301-2007
GB/T 17215.321-2008
GB/T 17215.322-2008
GB/T 17215.323-2008
《Measurement method of radio interference of high voltage overhead transmission lines and substations》
《General requirements, tests and test conditions for alternating current measuring equipment Part 11: measuring equipment》
《Special requirements for multifunctional watt hour meters》
《Special requirements for AC measuring equipment Part 21 static active energy meters (classes 1 and 2)》
《Special requirements for AC measuring equipment Part 22 static active watt hour meter (class 0.2S and class 0.5s)》
《Special requirements for AC measuring equipment Part 23 static reactive energy meters (classes 2 and 3)》
? Multipoint temperature detection
? Can signal quality test
? Automatic code scanning
? High and low temperature test
? Damp heat test
? Salinity test
? Pneumatic test
? Connection confirmation test
? Self test phase test
? Charging readiness test
? Start up and charging phase test
? Normal charge end test
? Charging connection control sequence test
? Abnormal charging test
? Output error test
? Electrostatic discharge immunity test
? Radio frequency electromagnetic field radiation immunity test
? Electrical fast transient burst immunity test
? Surge (impact) immunity test
? Immunity test of voltage sag, short interruption and voltage change
? Voltage withstand test
? insulation resistance
? Leakage current
? Switching on impulse current
? Turn off voltage
? Set response time
? Short circuit protection test
? Overvoltage protection test
? Overload protection test
? Over power protection test
? Input and output characteristic test
? Input harmonic detection
? Ripple test
? Current and voltage stabilization test
? Efficiency test
